Hydraulic Power:---------------------------30 Tons
Tube Size Range:---------------------------1/2? - 3? O.D.
Max. Capacity-Steel Tubing:----------------3? O.D. x .125? Wall
Max. Bend Angle:---------------------------165 degrees
Centerline Radius Range Permitting Bending to Max. Bend Angle:
	Maximum:---------------------------10? C.L.R.
	Minimum:---------------------------4? C.L.R.
Motor:-------------------------------------(2) 20 HP  3/60
Overall Dimensions (Approx.):--------------80? x 90? x 115? H
Weight (Est.):-----------------------------14,000 Lbs.

Pines Digital Dial-A-Bend Controls
Foot Switch
Bijur Lubrication
Pedestal Controls for: Motor Start 1
Motor Start 2, E-Stop, Reverse, Jog
Switch Controls for: Run/Jog,
Air Type Heat Exchanger

$9,950.00 FOB Chicago, IL

Payment prior to delivery

Immediate
