Capacity - Nominal (Mild Steel):-----------3/8" x 12'
Capacity ? At Full Rake (Mild Steel):------1/2" x 12'
Distance Between Housings:-----------------147"
Depth of Gap-------------------------------18"
Number of Holddowns:-----------------------15
Normal Holddown Force:---------------------26.5 Tons
Speed ? Minimum:---------------------------24 SPM
Speed - Maximum:---------------------------50 SPM
Distance Floor to Top of Bed:--------------32"
Motor:-------------------------------------30 HP  220/440V
Overall Dimensions (Approx.):--------------175" L-R x 86" F-B x 110" H
Weight (Est.):-----------------------------33,200 Lbs.

48? Front Operated Power Back Gauge with Read Out
Foot Switch Operation
10? Squaring Arm
(2) Front Support Arms
Power Rake Adjustment
Ball Transfers in Table
Centralized Lubrication System

$34,500.00 FOB Chicago, IL

Payment due with order

Immediate
